Cylinder - Single Acting

(No reviews yet) Write a Review
SKU:
033001/033005/033010/033011/033012/033013/033014/033035/033036/033037/033038/033039/033050/033060
UPC:
059629998083
Minimum Purchase:
1 unit
  • Cylinder - Single Acting
  • Cylinder - Single Acting
  • Cylinder - Single Acting
  • Cylinder - Single Acting
  • Cylinder - Single Acting
  • Cylinder - Single Acting
  • Cylinder - Single Acting
  • Cylinder - Single Acting
  • Cylinder - Single Acting
  • Cylinder - Single Acting
  • Cylinder - Single Acting
  • Cylinder - Single Acting
  • Cylinder - Single Acting
  • Cylinder - Single Acting
  • Cylinder - Single Acting
  • Cylinder - Single Acting
  • Cylinder - Single Acting
  • Cylinder - Single Acting
$693.79 - $6,471.86
Frequently bought together:

Description

Cylinder - Single Acting | STRONGARM

  • Complies with ANSI specifications
  • High strength alloy steel for safety and durability
  • Inside cylinder treated to enhance durability
  • Features collar threads, plunger threads and base mounting holes for optional fixture attachment
  • Heavy duty plunger spring return
  • High quality 3/8"-18 NPT quick coupling
  • Baked enamel finish for increased corrosion resistance

    • Available Options

    • 033001 (5 Metric Ton - .63" Stroke): Base Fixturing Holes - Bolt Circle U: 1.10" ; Base Fixturing Holes - Thread V: 0.22" ; Collapsed Height (A): 1.65" ; Cylinder Capacity @ 700 Bar (10,000 PSI): 5/5.5 Metric tons/US tons ; Cylinder Effective Area: 1.10 in² ; Extended Height (B): 2.28" ; Oil Capacity: 0,7 in³ ; Outside Diameter (D): 2.32" x 1.65" ; Piston Rod Diameter (F): 0.98" ; Product Weight: 1.8 lb (0.8 kg) ; Stroke: 0.63"
    • 033005 (5 Metric Ton - 5" Stroke): Base Fixturing Holes - Bolt Circle U: 0.98" ; Base Fixturing Holes - Thread Depth Z: 0.55" ; Base Fixturing Holes - Thread V: 1/4"-20UNC ; Collapsed Height (A): 8.46" ; Collar Thread (C): 1-1/2" - 16 ; Collar Thread Length (X): 1.1" ; Cylinder Capacity @ 700 Bar (10,000 PSI): 5/5.5 Metric tons/US tons ; Cylinder Effective Area: 1.10 in² ; Extended Height (B): 13.46" ; Oil Capacity: 5,5 in³ ; Outside Diameter (D): 1.5" ; Piston Internal Thread (O): 3/4"-16UNF ; Piston Rod Diameter (F): 0.98" ; Piston Thread Length (P): 0.63" ; Product Weight: 3.7 lb (1.7 kg) ; Stroke: 5"
    • 033010 (10 Metric Ton - 2.13" Stroke): Base Fixturing Holes - Bolt Circle U: 1.54" ; Base Fixturing Holes - Thread Depth Z: 0.47" ; Base Fixturing Holes - Thread V: 5/16"-18UNC ; Collapsed Height (A): 4.76" ; Collar Thread (C): 2-1/4" - 14 ; Collar Thread Length (X): 1.02" ; Cylinder Capacity @ 700 Bar (10,000 PSI): 10/11 Metric tons/US tons ; Cylinder Effective Area: 2.25 in² ; Extended Height (B): 6.89" ; Oil Capacity: 4,78 in³ ; Outside Diameter (D): 2.25" ; Piston Internal Thread (O): 1"-8UNC ; Piston Rod Diameter (F): 1.50" ; Piston Thread Length (P): 0.75" ; Product Weight: 3.7 lb (1.7 kg) ; Stroke: 2.13"
    • 033011 (10 Metric Ton - 4.13" Stroke): Base Fixturing Holes - Bolt Circle U: 1.54" ; Base Fixturing Holes - Thread Depth Z: 0.47" ; Base Fixturing Holes - Thread V: 5/16"-18UNC ; Collapsed Height (A): 6.73" ; Collar Thread (C): 2-1/4" - 14 ; Collar Thread Length (X): 1.02" ; Cylinder Capacity @ 700 Bar (10,000 PSI): 10/11 Metric tons/US tons ; Cylinder Effective Area: 2.25 in² ; Extended Height (B): 10.87" ; Oil Capacity: 9,29 in³ ; Outside Diameter (D): 2.25" ; Piston Internal Thread (O): 1"-8UNC ; Piston Rod Diameter (F): 1.50" ; Piston Thread Length (P): 0.75" ; Product Weight: 6.4 lb (3 kg) ; Stroke: 4.13"
    • 033012 (10 Metric Ton - 6.14" Stroke): Base Fixturing Holes - Bolt Circle U: 1.54" ; Base Fixturing Holes - Thread Depth Z: 0.47" ; Base Fixturing Holes - Thread V: 5/16"-18UNC ; Collapsed Height (A): 9.72" ; Collar Thread (C): 2-1/4" - 14 ; Collar Thread Length (X): 1.02" ; Cylinder Capacity @ 700 Bar (10,000 PSI): 10/11 Metric tons/US tons ; Cylinder Effective Area: 2.25 in² ; Extended Height (B): 15.87" ; Oil Capacity: 13,8 in³ ; Outside Diameter (D): 2.25" ; Piston Internal Thread (O): 1"-8UNC ; Piston Rod Diameter (F): 1.50" ; Piston Thread Length (P): 0.75" ; Product Weight: 9.1 lb (4.1 kg) ; Stroke: 6.14"
    • 033013 (10 Metric Ton - 7.99" Stroke): Base Fixturing Holes - Bolt Circle U: 1.54" ; Base Fixturing Holes - Thread Depth Z: 0.47" ; Base Fixturing Holes - Thread V: 5/16"-18UNC ; Collapsed Height (A): 11.73" ; Collar Thread (C): 2-1/4" - 14 ; Collar Thread Length (X): 1.02" ; Cylinder Capacity @ 700 Bar (10,000 PSI): 10/11 Metric tons/US tons ; Cylinder Effective Area: 2.25 in² ; Extended Height (B): 19.72" ; Oil Capacity: 17,96 in³ ; Outside Diameter (D): 2.25" ; Piston Internal Thread (O): 1"-8UNC ; Piston Rod Diameter (F): 1.50" ; Piston Thread Length (P): 0.75" ; Product Weight: 10.8 lb (4.9 kg) ; Stroke: 7.99"
    • 033014 (10 Metric Ton - 10.12" Stroke): Base Fixturing Holes - Bolt Circle U: 1.54" ; Base Fixturing Holes - Thread Depth Z: 0.47" ; Base Fixturing Holes - Thread V: 5/16"-18UNC ; Collapsed Height (A): 13.74" ; Collar Thread (C): 2-1/4" - 14 ; Collar Thread Length (X): 1.02" ; Cylinder Capacity @ 700 Bar (10,000 PSI): 10/11 Metric tons/US tons ; Cylinder Effective Area: 2.25 in² ; Extended Height (B): 23.86" ; Oil Capacity: 22,73 in³ ; Outside Diameter (D): 2.25" ; Piston Internal Thread (O): 1"-8UNC ; Piston Rod Diameter (F): 1.50" ; Piston Thread Length (P): 0.75" ; Product Weight: 12.3 lb (5.6 kg) ; Stroke: 10.12"
    • 033035 (25 Metric Ton - 1.97" Stroke): Base Fixturing Holes - Bolt Circle U: 2.28" ; Base Fixturing Holes - Thread Depth Z: 0.75" ; Base Fixturing Holes - Thread V: 1/2"-13UNC ; Collapsed Height (A): 6.5" ; Collar Thread (C): 3-5/16" - 12 ; Collar Thread Length (X): 2.13" ; Cylinder Capacity @ 700 Bar (10,000 PSI): 25/27.5 Metric tons/US tons ; Cylinder Effective Area: 5.15 in² ; Extended Height (B): 8.46" ; Oil Capacity: 10,13 in³ ; Outside Diameter (D): 3.39" ; Piston Internal Thread (O): 1-1/2"-16UN ; Piston Rod Diameter (F): 2.24" ; Piston Thread Length (P): 1.02" ; Product Weight: 13.6 lb (6.2 kg) ; Stroke: 1.97"
    • 033036 (25 Metric Ton - 4.02" Stroke): Base Fixturing Holes - Bolt Circle U: 2.28" ; Base Fixturing Holes - Thread Depth Z: 0.75" ; Base Fixturing Holes - Thread V: 1/2"-13UNC ; Collapsed Height (A): 8.46" ; Collar Thread (C): 3-5/16" - 12 ; Collar Thread Length (X): 2.13" ; Cylinder Capacity @ 700 Bar (10,000 PSI): 25/27.5 Metric tons/US tons ; Cylinder Effective Area: 5.15 in² ; Extended Height (B): 12.48" ; Oil Capacity: 20,66 in³ ; Outside Diameter (D): 3.39" ; Piston Internal Thread (O): 1-1/2"-16UN ; Piston Rod Diameter (F): 2.24" ; Piston Thread Length (P): 1.02" ; Product Weight: 17.6 lb (8 kg) ; Stroke: 4.02"
    • 033037 (25 Metric Ton - 6.22" Stroke): Base Fixturing Holes - Bolt Circle U: 2.28" ; Base Fixturing Holes - Thread Depth Z: 0.75" ; Base Fixturing Holes - Thread V: 1/2"-13UNC ; Collapsed Height (A): 10.75" ; Collar Thread (C): 3-5/16" - 12 ; Collar Thread Length (X): 2.13" ; Cylinder Capacity @ 700 Bar (10,000 PSI): 25/27.5 Metric tons/US tons ; Cylinder Effective Area: 5.15 in² ; Extended Height (B): 16.97" ; Oil Capacity: 32 in³ ; Outside Diameter (D): 3.39" ; Piston Internal Thread (O): 1-1/2"-16UN ; Piston Rod Diameter (F): 2.24" ; Piston Thread Length (P): 1.02" ; Product Weight: 22.75 lb (10.3 kg) ; Stroke: 6.22"
    • 033038 (25 Metric Ton - 8.27" Stroke): Base Fixturing Holes - Bolt Circle U: 2.28" ; Base Fixturing Holes - Thread Depth Z: 0.75" ; Base Fixturing Holes - Thread V: 1/2"-13UNC ; Collapsed Height (A): 12.72" ; Collar Thread (C): 3-5/16" - 12 ; Collar Thread Length (X): 2.13" ; Cylinder Capacity @ 700 Bar (10,000 PSI): 25/27.5 Metric tons/US tons ; Cylinder Effective Area: 5.15 in² ; Extended Height (B): 20.98" ; Oil Capacity: 42,53 in³ ; Outside Diameter (D): 3.39" ; Piston Internal Thread (O): 1-1/2"-16UN ; Piston Rod Diameter (F): 2.24" ; Piston Thread Length (P): 1.02" ; Product Weight: 26.6 lb (12.1 kg) ; Stroke: 8.27"
    • 033039 (25 Metric Ton - 10.28" Stroke): Base Fixturing Holes - Bolt Circle U: 2.28" ; Base Fixturing Holes - Thread Depth Z: 0.75" ; Base Fixturing Holes - Thread V: 1/2"-13UNC ; Collapsed Height (A): 14.72" ; Collar Thread (C): 3-5/16" - 12 ; Collar Thread Length (X): 2.13" ; Cylinder Capacity @ 700 Bar (10,000 PSI): 25/27.5 Metric tons/US tons ; Cylinder Effective Area: 5.15 in² ; Extended Height (B): 25" ; Oil Capacity: 52,86 in³ ; Outside Diameter (D): 3.39" ; Piston Internal Thread (O): 1-1/2"-16UN ; Piston Rod Diameter (F): 2.24" ; Piston Thread Length (P): 1.02" ; Product Weight: 31 lb (14.1 kg) ; Stroke: 10.28"
    • 033050 (50 Metric Ton - 6.26" Stroke): Base Fixturing Holes - Bolt Circle U: 3.74" ; Base Fixturing Holes - Thread Depth Z: 0.75" ; Base Fixturing Holes - Thread V: 1/2"-13UNC ; Collapsed Height (A): 11.1" ; Collar Thread (C): 5" - 12 ; Collar Thread Length (X): 2.17" ; Cylinder Capacity @ 700 Bar (10,000 PSI): 50/55 Metric tons/US tons ; Cylinder Effective Area: 10.99 in² ; Extended Height (B): 17.36" ; Oil Capacity: 68,77 in³ ; Outside Diameter (D): 5.00" ; Piston Rod Diameter (F): 3.15" ; Product Weight: 48.8 lb (22.1 kg) ; Stroke: 6.26"
    • 033060 (100 Metric Ton - 6.61" Stroke): Base Fixturing Holes - Bolt Circle U: 5.47" ; Base Fixturing Holes - Thread Depth Z: 0.98" ; Base Fixturing Holes - Thread V: 3/4"-10UNC ; Collapsed Height (A): 14.06" ; Collar Thread (C): 6-7/8" - 12 ; Collar Thread Length (X): 1.73" ; Cylinder Capacity @ 700 Bar (10,000 PSI): 95/104.7 Metric tons/US tons ; Cylinder Effective Area: 20.62 in² ; Extended Height (B): 20.67" ; Oil Capacity: 136,3 in³ ; Outside Diameter (D): 6.97" ; Piston Rod Diameter (F): 4.13" ; Product Weight: 131.3 lb (59.6 kg) ; Stroke: 6.61"
